Daikin Ducted Split Air Conditioner 1.5 Ton | 5.3 kW | 2.0 HP | 18,000 Btu/h FDMRN20AV1KU / RR20AV1KU

Key features

The Daikin FDMRN20AV1KU / RR20AV1KU is designed to deliver quiet, powerful, and discreet cooling through a concealed ceiling installation. It provides an invisible cooling solution for spaces where comfort, aesthetics, and efficient performance are important. Key Features Feature Details Brand Daikin Series FDMRN Series Indoor Model FDMRN20AV1KU Outdoor Model RR20AV1KU...

Shop with confidence

Payment Badge
Fast Delivery
Payment Badge
Buy Now Pay Later
Payment Badge
Secure Payments
Payment Badge
Trusted Quality

The Daikin FDMRN20AV1KU / RR20AV1KU is designed to deliver quiet, powerful, and discreet cooling through a concealed ceiling installation. It provides an invisible cooling solution for spaces where comfort, aesthetics, and efficient performance are important.

Key Features

Feature Details
Brand Daikin
Series FDMRN Series
Indoor Model FDMRN20AV1KU
Outdoor Model RR20AV1KU
Product Type Concealed ceiling AC
Cooling Type Cooling only
Refrigerant R-410A
Installation Type Concealed ceiling / ducted installation
Design Style Hidden indoor unit design
Main Use Villas, apartments, offices, hotels, and commercial interiors

Product Features

Feature Description
Concealed Ceiling Design Installed inside the ceiling to keep the indoor space clean, modern, and unobtrusive.
R-410A Refrigerant Uses R-410A refrigerant with zero ozone depletion potential.
Powerful Cooling Provides fast and reliable cooling even when outdoor temperature is high.
Energy Saving Performance Designed for efficient cooling with reduced electricity consumption.
Optimal Cooling Comfort Includes Turbo Mode, Sleep Mode, and Dry Mode for better indoor comfort.
Whisper Quiet Operation Operates quietly to maintain a peaceful indoor environment.
Long Airflow Helps distribute cool air over longer distances for better room coverage.
High Design Flexibility Wide static pressure range allows flexible duct design and installation.
Easy Installation Outdoor unit can be mounted on a roof or placed against an outside wall.
Anti-Corrosion Protection Outdoor unit components are protected for longer service life.
Double Drain Pan Protection Helps reduce the risk of water leakage.
Auto Random Restart Automatically restarts after power failure and helps prevent power surge issues.

Technical Parameters

Specification Details
Indoor Model FDMRN20AV1KU
Outdoor Model RR20AV1KU
Power Supply 230V / 1Ph / 50Hz
Cooling Capacity T1 18,000 Btu/h / 5.28 kW
Cooling Capacity T3 15,750 Btu/h / 4.62 kW
EER T1 11.91 Btu/h/W
EER T3 8.73 Btu/h/W
ESP Range High Fan 40 / 50 Pa
Indoor Airflow 721 / 618 / 432 CFM
Indoor Sound Level 41 / 39 / 36 dB(A)
Indoor Dimensions 261 × 1,137 × 388 mm
Refrigerant Type R-410A
Compressor Type Rotary
Outdoor Dimensions 753 × 855 × 328 mm
Liquid Pipe Connection 6.35 mm / 1/4 inch
Gas Pipe Connection 12.7 mm / 1/2 inch
Total Piping Length 50 m
Vertical Piping Length 30 m
Operating Temperature Range 19°C – 52°C

Application Scope

Application Area Details
Residential Spaces Suitable for bedrooms, living rooms, villas, and apartments.
Hotels Ideal for guest rooms and suites where hidden cooling is preferred.
Offices Provides quiet ducted cooling without affecting interior design.
Retail Shops Maintains comfort while keeping the AC unit concealed.
Commercial Interiors Suitable for spaces requiring flexible ducted cooling installation.

Main Benefits

  • Hidden ceiling-mounted design
  • 18,000 Btu/h cooling capacity
  • Quiet indoor operation
  • R-410A refrigerant with zero ozone depletion potential
  • Long airflow for better comfort
  • Flexible duct installation
  • Anti-corrosion protection
  • Double drain pan leakage protection
  • Auto random restart after power failure
  • Suitable for residential and commercial spaces
